Product Introduction:
Pneumatic ventilation butterfly valve (flue gas damper) is a center-line welded butterfly valve, driven by pneumatic actuator.
The disc rotates within 0°~90° to realize pipeline on-off and air volume regulation.
It is designed for low-pressure & large-flow gas ductwork, suitable for air, hot air, dust-laden flue gas and industrial waste gas.
Standard version is non-sealing with minor leakage. Metal hard seal or soft seal can be customized according to working conditions.
Main Features:
Fast opening & closing, quick response, ideal for emergency shut-off system.
Stable continuous operation, suitable for frequent switch cycles.
Low flow resistance at fully open position, reduce fan energy consumption.
Welded body without internal linkages, anti-dust accumulation, anti-jamming.
Two actuator options: double-acting / single-acting (spring return).Single-acting type achieves fail-open / fail-close when air supply lost.
Multiple control modes: on-off type or modulating type with positioner.
Explosion-proof accessories optional for flammable gas pipeline.
Reminder: Stable clean compressed air (0.4~0.6 MPa) is required on site.
Technical Data:
Size: DN100 ~ DN6000.
Nominal Pressure: PN0.1 / PN0.25 / PN0.6 MPa.
Connection: Flanged / Wafer.
Air Supply Pressure: 0.4 ~ 0.6 MPa.
Actuator: Double-acting / Single-acting spring return.
Control: On-off (solenoid + limit switch); Modulating (4~20mA positioner).
Body & Disc Material: Q235 Carbon Steel, WCB, SS304, SS316L, SS310S.
Temperature Range: -40℃ ~ 950℃ (subject to material).
Seal Type: Non-sealing / Metal Hard Seal / Soft Seal.
Medium: Air, hot air, flue gas, dust gas, waste gas, coal gas.
Application:
Power plant desulfurization & denitrification, cement kilns, metallurgical flue pipelines, dust removal system, waste incineration, chemical exhaust, HVAC ventilation.
