Product Introduction:
J41 series stainless steel globe valve is forced-sealing straight pattern globe valve.
J41W Stainless Steel Flanged Globe Valve. CF8(304)/CF8M(316) corrosion resistant body with integral metal seal.
Ideal for pure water, food liquid, seawater and corrosive chemical pipelines in pharmaceutical, environmental and chemical industry.
Handwheel drives stem and disc to control fluid shut-off and slight throttling. Medium flows upward from below disc.
Outstanding acid & corrosion resistance, widely used for chemical, food, water treatment, seawater desalination and pharmaceutical pipelines.
Main Features
1.Corrosion resistant stainless steel body
CF8(304) for mild corrosive media; CF8M(316) resists chloride ion for seawater service.
2.Two trim options
J41W: integral stainless steel seat for pure fluid & food grade service.
J41Y: Stellite hardfacing trim for anti-abrasion, frequent operation conditions.
3.Bolted bonnet, convenient for on-site maintenance.
4.S-type flow passage; continuous partial opening operation is not recommended.
5.Manual standard; electric and pneumatic actuator available.
Specifications:
Operation type:Manual-Hand wheel
Size: DN50-DN250
Pressure: PN10/16/ Class125/150,JIS6K/10K
Face to Face Standard: API609,BS5155,DIN3202,ISO5752
Flange Standard:DIN,BS,ISO,ANSI,AS,JIS
Materials:
Body : Stainless Steel
Disc: Stainless Steel
Packing:PTFE + Graphite
Gasket: Graphite
Stem : Stainless Steel
Characteristic:
Applicable Medium: Water, Oil, Gas
Applicable Temperature:-29~425
All valves are equipped with professional export protective packaging.
With protective caps on the sealing surfaces, rust-proof treatment, and shock-absorbing material filling to ensure intact transport; the loading is secure and safe.
We can also customize packaging according to customer requirements.
Regarding transportation methods, we can provide appropriate transportation options based on the cargo requirements and the customer's timeliness requirements.
Common transportation methods include: sea freight, air freight, land freight, and express delivery.
