Product Introduction:
ANSI carbon steel globe valve adopts A216 WCB carbon steel body.
Designed & manufactured according to ASME B16.34, API 602. Flange dimension ASME B16.5, face-to-face ASME B16.10, testing per API 598.It is forced-sealing globe valve.
The stem drives disc upward and downward to realize shut-off and throttling. Medium flows from below disc to outlet.
Widely used in petrochemical, power plant, heating system, overseas EPC projects for steam, oil and industrial fluid service.
Important Note: WCB steel valve complies with ASME B16.5, which is not interchangeable with cast iron Class125/250 (ASME B16.1).
Main Features
Forced tight sealing design, reliable shut-off and throttling performance.
Bolted bonnet standard; pressure seal bonnet optional for high pressure & high temperature service.
Trim options: Cr13 hard face or Stellite hardfacing for anti-abrasion.
A216 WCB body works steadily under high temperature and pressure, resistant to water hammer and impact load.
Full ANSI standard dimension, compatible with worldwide industrial piping systems.
Specifications:
Operation type:Manual-Hand wheel
Size: DN50-DN1200
Pressure: PN10/16/ Class125/150,JIS6K/10K
Face to Face Standard: API609,BS5155,DIN3202,ISO5752
Flange Standard:DIN,BS,ISO,ANSI,AS,JIS
Materials:
Body : WCB
Disc: WCB
Packing:PTFE + Graphite
Gasket: Graphite
Stem : Stainless Steel
Characteristic:
Applicable Medium: Water, Oil, Gas
Applicable Temperature:-29~425℃
All valves are equipped with professional export protective packaging.
With protective caps on the sealing surfaces, rust-proof treatment, and shock-absorbing material filling to ensure intact transport; the loading is secure and safe.
We can also customize packaging according to customer requirements.
Regarding transportation methods, we can provide appropriate transportation options based on the cargo requirements and the customer's timeliness requirements.
Common transportation methods include: sea freight, air freight, land freight, and express delivery.
